The panel bending machine is equipped with an Industry 4.0-ready interface, allowing seamless integration with robotic arms for fully automated loading and unloading, boosting productivity and reducing manual handling.
This panel bending machine integrates seamlessly with the Lichuan self-driven robotic arm, sharing the same control system for unified operation. No secondary programming is required when changing workpieces—the system automatically generates arm movements based on bending commands, ensuring higher efficiency and perfectly synchronized performance.
The LC-XP suction cup type CNC panel bender supports customization for 4mm steel, 2mm reinforced stainless steel, and a 600mm throat height, meeting various bending needs with ease.
| LC-2500XP(suction cup type) | |
| Feeding method | Suction cup |
| Positioning method | Y-axis ruler |
| Suitable material | Stainless steel, aluminum plate, cold plate and other metal materials |
| Minimum thickness of sheet | 0.15mm |
| Maximum thickness of plate | UTS 520N/mm² stainless steel 1.2mm UTS 410N/mm² galvanized sheet and ordinary carbon steel sheet 2.0mm UTS 265N/n m² aluminum sheet 3.5mm |
| Dimensions of sheet material | Max. 2500×2500 mm |
| Minimum size after processing | Minimum 380-420 mm (opening size, excluding inner edge) |
| Plate requirements | Smooth surface, no burrs on the edges, accurate cutting dimensions |
The LC-XP (suction cup type) CNC panel bender is ideal for sheets under 1mm thick and comes equipped with a fully automatic knife splicing system and code scanning recognition for smarter, more efficient operation.
| Configuration Parameters | LC-2500XP(suction cup type) |
| Fastest bending speed | 0.3 seconds/knife |
| Maximum bending throat height | 180mm (can be customized to 600mm height) |
| Suitable material | Stainless steel, aluminum plate, cold plate and other metal materials |
| Rated voltage | 380V |
| Motor total power | About 50KW |
| Average energy consumption | About 8KW per hour |
| Noise | About 50dB |
| Dimensions | 540×460×280 cm |
| Total mass | About 15T |
| Number of axes | Standard 10 axes |
| Fully automatic computer knife splicing and code scanning recognition | Optional |
The LC-YB (press arm type) CNC panel bender can be customized for 4mm steel, 2mm reinforced stainless steel, and a 600mm throat height to suit various bending needs.
| LC-2500XP (arm pressure type) | |
| Feeding method | Press Arm |
| Positioning method | Y-axis ruler |
| Suitable material | Stainless steel, aluminum plate, cold plate and other metal materials |
| Minimum thickness of sheet | 0.15mm |
| Maximum thickness of plate | UTS 520N/mm² stainless steel 1.2mm UTS 410N/mm² galvanized sheet and ordinary carbon steel sheet 2.0mm UTS 265N/mm² aluminum sheet 3.5mm |
| Dimensions of sheet material | Max. 2500x2500 mm |
| Minimum size after processing | Minimum 280-420 mm (opening R size, excluding inner edge) |
| Plate requirements | The surface is smooth, the edges are green and burr-free, and the cutting size is accurate |
The LC-YB (arm pressure type) CNC panel bender is suitable for sheets under 1mm and features a fully automatic knife splicing system with code scanning recognition for efficient and intelligent operation.
| Configuration parameters | LC-2500XP (arm pressure type) |
| Fastest bending speed | 0.3 seconds/knife |
| Maximum bending throat height | 180mm (can be customized to 600mm height) |
| Suitable material | Stainless steel, aluminum plate, cold plate and other metal materials |
| Rated voltage | 380V |
| Motor total power | About 45KW |
| Average energy consumption | About 8KW/hour |
| Noise | About 50dB |
| Dimensions | 600x460×280 cm |
| Total mass | About 17T |
| Axis Number | Standard 12 axes |
| Fully automatic computer knife splicing and code scanning recognition | Optional |
