The automatic panel bending machine features an Industry 4.0-compatible interface, enabling seamless connection with robotic arms for fully automated loading and unloading processes.
Equipped with the Lichuan self-driven robotic arm, our automatic panel bender shares the same control system as the bending center, eliminating the need for secondary programming during workpiece changes. The system automatically generates robotic arm movements based on bending commands, enhancing efficiency and coordination.
The LC-XP (suction cup type) automatic panel bender offers customization options including support for 4mm steel plates, a reinforced 2mm stainless steel version, and an adjustable 600mm throat height to meet diverse bending requirements.
| LC-2200XP(suction cup type) | |
| Feeding method | Suction cup |
| Positioning method | Y-axis ruler |
| Suitable material | Stainless steel, aluminum plate, cold plate and other metal materials |
| Minimum thickness of sheet | 0.15mm |
| Maximum thickness of plate | UTS 520N/mm² stainless steel 1.2mm UTS 410N/mm² galvanized sheet and ordinary carbon steel sheet 2.0mm UTS 265N/n m² aluminum sheet 3.5mm |
| Dimensions of sheet material | Max. 2200×2200 mm |
| Minimum size after processing | Minimum 280-420 mm (opening size, excluding inner edge) |
| Plate requirements | Smooth surface, no burrs on the edges, accurate cutting dimensions |
The LC-XP (suction cup type) automatic panel bender is designed for sheets under 1mm and features a fully automated knife splicing system along with code scanning recognition for streamlined, intelligent operation.
| Configuration Parameters | LC-2200XP(suction cup type) |
| Fastest bending speed | 0.3 seconds/knife |
| Maximum bending throat height | 180mm (can be customized to 600mm height) |
| Suitable material | Stainless steel, aluminum plate, cold plate and other metal materials |
| Rated voltage | 380V |
| Motor total power | About 40KW |
| Average energy consumption | About 4KW per hour |
| Noise | About 50dB |
| Dimensions | 520×420×280 cm |
| Total mass | About 14T |
| Number of axes | Standard 10 axes |
| Fully automatic computer knife splicing and code scanning recognition | Optional |
The LC-YB (press arm type) automatic panel bender can be tailored to handle 4mm steel plates, reinforced 2mm stainless steel, and offers a customizable 600mm throat height to suit various heavy-duty bending tasks.
| LC-2200XP (arm pressure type) | |
| Feeding method | Press Arm |
| Positioning method | Y-axis ruler |
| Suitable material | Stainless steel, aluminum plate, cold plate and other metal materials |
| Minimum thickness of sheet | 0.15mm |
| Maximum thickness of plate | UTS 520N/mm² stainless steel 1.2mm UTS 410N/mm² galvanized sheet and ordinary carbon steel sheet 2.0mm UTS 265N/mm² aluminum sheet 3.5mm |
| Dimensions of sheet material | Max. 2200x2200 mm |
| Minimum size after processing | Minimum 280-420 mm (opening R size, excluding inner edge) |
| Plate requirements | The surface is smooth, the edges are green and burr-free, and the cutting size is accurate |
The LC-YB (arm pressure type) automatic panel bender is ideal for sheets under 1mm and comes equipped with a fully automated knife splicing system and code scanning recognition for efficient, intelligent operation.
| Configuration parameters | LC-2200XP (arm pressure type) |
| Fastest bending speed | 0.3 seconds/knife |
| Maximum bending throat height | 180mm (can be customized to 600mm height) |
| Suitable material | Stainless steel, aluminum plate, cold plate and other metal materials |
| Rated voltage | 380V |
| Motor total power | About 45KW |
| Average energy consumption | About 4KW/hour |
| Noise | About 50dB |
| Dimensions | 560x420×280 cm |
| Total mass | About 16T |
| Axis Number | Standard 12 axes |
| Fully automatic computer knife splicing and code scanning recognition | Optional |
